MODEL SPECS |
21-litre
panniers
Built-in
DC and USB outlets
Click on a technology to learn more.
| Chassis Management Technology |
| Maximum Power | 28.5 kW {39 PS} / 6,000 rpm |
| Maximum Torque | 51.5 Nm {5.3 kgfm} / 4,500 rpm |
| Engine | 4-stroke Single |
| Displacement | 652 cc |
| Bore x Stroke | 100.0 x 83.0 mm |
| Compression Ratio | 9.8:1 |
| Valve System | DOHC, 4 valves |
| Fuel System | Fuel injection: ø40 mm x 1 |
| Ignition | Transistorised ignition |
| Starting | Electric |
| Cooling | Liquid-cooled |
| Lubrication | Forced lubrication, wet sump |
| Transmission | 5-speed, return |
| Primary Reduction Ratio | 2.273 (75/33) |
| Gear Ratio: 1st | 2.267 (34/15) |
| Gear Ratio: 2nd | 1.444 (26/18) |
| Gear Ratio: 3rd | 1.136 (25/22) |
| Gear Ratio: 4th | 0.955 (21/22) |
| Gear Ratio: 5th | 0.792 (19/24) |
| Final Reduction Ratio | 2.867 (43/15) |
| Clutch | Wet multi-disc, manual |
| Final Drive | Chain |
| Frame | Semi-double cradle, high-tensile steel |
| Front Suspension | ø41 mm telescopic fork |
| Rear Suspension | Uni Trak, single shock with adjustable rebound damping and adjustable spring preload |
| Front Wheel Travel | 200 mm |
| Rear Wheel Travel | 202 mm |
| Rake | 30° |
| Trail | 121 mm |
| Steering Angle (L/R) | 44° / 44° |
| Front Tyre | 90/90-21M/C 54S |
| Rear Tyre | 130/80-17M/C 65S |
| Front Brake/s | ø300 mm disc |
| Front Caliper/s | Dual-piston |
| Rear Brake | ø240 mm disc |
| Rear Caliper | Dual-piston |
| Dimensions (LxWxH) | 2,280 x 970 x 1,455/1,420 mm (high/low) |
| Wheelbase | 1,540 mm |
| Road Clearance | 210 mm |
| Seat Height | 870 mm |
| Curb Weight* | 222 kg |
| Fuel Capacity | 23 litres |
| Model Code | KL650HRFAN |
*Curb weight includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
**Estimated dry weight does not include all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
KAWASAKI CARES: Always wear a helmet, eye protection, and proper apparel. Never ride under the influence of drugs or alcohol. Read Owner’s Manual and all on-product warnings. Professional rider shown on a closed course. 2021 Kawasaki Motors Pty Ltd.
Specifications subject to change.
