MODEL SPECS |
Click on a technology to learn more.
| Engine Management Technology |
| Chassis Management Technology |
| Maximum Power | 91.0 kW {124 PS} / 13,000 rpm |
| Maximum Power with Ram Air | 95.2 kW {129 PS} / 13,000 rpm |
| Maximum Torque | 69.0 Nm {7.0 kgfm} / 11,000 rpm |
| Engine | 4-stroke In-Line Four |
| Displacement | 636 cc |
| Bore x Stroke | 67.0 x 45.1 mm |
| Compression Ratio | 12.9:1 |
| Valve System | DOHC, 16 valves |
| Fuel System | Fuel injection: ø38 mm x 4 with oval sub-throttles |
| Ignition | Digital |
| Starting | Electric |
| Cooling | Liquid-cooled |
| Lubrication | Forced lubrication, wet sump |
| Transmission | 6-speed, return |
| Primary Reduction Ratio | 1.900 (76/40) |
| Gear Ratio: 1st | 2.846 (37/13) |
| Gear Ratio: 2nd | 2.200 (33/15) |
| Gear Ratio: 3rd | 1.850 (37/20) |
| Gear Ratio: 4th | 1.600 (32/20) |
| Gear Ratio: 5th | 1.421 (27/19) |
| Gear Ratio: 6th | 1.300 (26/20) |
| Final Reduction Ratio | 2.867 (43/15) |
| Clutch | Wet multi-disc, manual |
| Final Drive | Chain |
| Frame | Perimeter, pressed-aluminium |
| Front Suspension | ø41 mm inverted fork (SFF-BP) with rebound and compression damping and spring preload adjustability |
| Rear Suspension | Bottom-Link Uni Trak, gas-charged shock with piggyback reservoir, compression and rebound damping and spring preload adjustability |
| Front Wheel Travel | 120 mm |
| Rear Wheel Travel | 151 mm |
| Rake | 23.5° |
| Trail | 101 mm |
| Steering Angle (L/R) | 27° / 27° |
| Front Tyre | 120/70ZR17M/C (58W) |
| Rear Tyre | 180/55ZR17M/C (73W) |
| Front Brake/s | Dual semi-floating ø310 mm discs |
| Front Caliper/s | Radial-mount, monobloc, opposed 4-piston |
| Rear Brake | ø220 mm disc |
| Rear Caliper | Single-bore pin-slide aluminium-piston |
| Dimensions (LxWxH) | 2,025 x 710 x 1,105 mm |
| Wheelbase | 1,400 mm |
| Road Clearance | 130 mm |
| Seat Height | 830 mm |
| Curb Weight* | 198 kg |
| Estimated Dry Weight** | 179 kg |
| Fuel Capacity | 17 litres |
| Model Code | ZX636JTFAN |
*Curb weight includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
**Estimated dry weight does not include all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
KAWASAKI CARES: Always wear a helmet, eye protection, and proper apparel. Never ride under the influence of drugs or alcohol. Read Owner’s Manual and all on-product warnings. Professional rider shown on a closed course. 2021 Kawasaki Motors Pty Ltd.
Specifications subject to change.
