MODEL SPECS |
Click on a technology to learn more.
| Engine Management Technology |
| Chassis Management Technology |
| Maximum Power | 29.3 kW {40 PS} / 11,500 rpm |
| Maximum Torque | 25.7 Nm {2.6 kgfm} / 10,000 rpm |
| Engine | 4-stroke Parallel Twin |
| Displacement | 296 cc |
| Bore x Stroke | 62.0 x 49.0 mm |
| Compression Ratio | 10.6:1 |
| Valve System | DOHC, 8 valves |
| Fuel System | Fuel injection: ø32 mm x 2 with dual throttle valves |
| Ignition | Digital |
| Starting | Electric |
| Cooling | Liquid-cooled |
| Lubrication | Forced lubrication, wet sump |
| Transmission | 6-speed, return |
| Primary Reduction Ratio | 3.087 (71/23) |
| Gear Ratio: 1st | 2.714 (38/14) |
| Gear Ratio: 2nd | 1.789 (34/19) |
| Gear Ratio: 3rd | 1.409 (31/22) |
| Gear Ratio: 4th | 1.160 (29/25) |
| Gear Ratio: 5th | 1.000 (27/27) |
| Gear Ratio: 6th | 0.857 (24/28) |
| Final Reduction Ratio | 3.286 (46/14) |
| Clutch | Wet multi-disc, manual |
| Final Drive | Chain |
| Frame | Backbone, high-tensile steel |
| Front Suspension | ø41 mm telescopic fork |
| Rear Suspension | Bottom-Link Uni Trak, gas-charged shock with adjustable preload |
| Front Wheel Travel | 130 mm |
| Rear Wheel Travel | 148 mm |
| Rake | 24.3° |
| Trail | 108 mm |
| Steering Angle (L/R) | 40° / 40° |
| Front Tyre | 100/90-19M/C 57S |
| Rear Tyre | 130/80-17M/C 65S |
| Front Brake/s | ø290 mm petal disc |
| Front Caliper/s | Balanced-actuation dual-piston |
| Rear Brake | ø220 mm petal disc |
| Rear Caliper | Dual-piston |
| Dimensions (LxWxH) | 2,170 x 860 x 1,390 mm |
| Wheelbase | 1,450 mm |
| Road Clearance | 180 mm |
| Seat Height | 815 mm |
| Curb Weight* | 175 kg |
| Estimated Dry Weight** | 159 kg |
| Fuel Capacity | 17 litres |
| Model Code | KLE300CSFAN |
*Curb weight includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
**Estimated dry weight does not include all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
KAWASAKI CARES: Always wear a helmet, eye protection, and proper apparel. Never ride under the influence of drugs or alcohol. Read Owner’s Manual and all on-product warnings. Professional rider shown on a closed course. 2021 Kawasaki Motors Pty Ltd.
Specifications subject to change.
