MODEL SPECS |
Larger wheels and
taller seat height
Front and rear
disc brakes
| Maximum Power | 8.3 kW {11 PS} / 8,000 rpm |
| Maximum Torque | 12.0 Nm {1.2 kgfm} / 6,000 rpm |
| Engine | 4-stroke Single |
| Displacement | 144 cc |
| Bore x Stroke | 58.0 x 54.4 mm |
| Compression Ratio | 9.5:1 |
| Valve System | SOHC, 2 valves |
| Fuel System | Carburettor: Keihin PB20 |
| Ignition | Digital DC-CDI |
| Starting | Electric |
| Cooling | Air-cooled |
| Lubrication | Forced lubrication, wet sump |
| Transmission | 5-speed, return |
| Primary Reduction Ratio | 2.880 (72/25) |
| Gear Ratio: 1st | 2.667 (40/15) |
| Gear Ratio: 2nd | 1.895 (36/19) |
| Gear Ratio: 3rd | 1.474 (28/19) |
| Gear Ratio: 4th | 1.182 (26/22) |
| Gear Ratio: 5th | 1.000 (24/24) |
| Final Reduction Ratio | 3.923 (51/13) |
| Clutch | Wet multi-disc, manual |
| Final Drive | Chain |
| Frame | Perimeter, box-section, high-tensile steel |
| Front Suspension | ø33 mm telescopic fork |
| Rear Suspension | Uni Trak, single shock with piggyback reservoir, adjustable compression and rebound damping, and adjustable spring preload |
| Front Wheel Travel | 180 mm |
| Rear Wheel Travel | 180 mm |
| Rake | 27.0° |
| Trail | 96 mm |
| Steering Angle (L/R) | 41° / 41° |
| Front Tyre | 70/100-19 42M |
| Rear Tyre | 90/100-16 52M |
| Front Brake/s | ø220 mm petal disc |
| Front Caliper/s | Dual-piston |
| Rear Brake | ø186 mm petal disc |
| Rear Caliper | Single-piston |
| Dimensions (LxWxH) | 1,895 x 790 x 1,075 mm |
| Wheelbase | 1,285 mm |
| Road Clearance | 255 mm |
| Seat Height | 800 mm |
| Curb Weight* | 95 kg |
| Estimated Dry Weight** | 89 kg |
| Fuel Capacity | 5.8 litres |
| Model Code | KLX140BTFNN |
*Curb weight includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
**Estimated dry weight does not include all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
KAWASAKI CARES: Always wear a helmet, eye protection, and proper apparel. Never ride under the influence of drugs or alcohol. Read Owner’s Manual and all on-product warnings. Professional rider shown on a closed course. 2021 Kawasaki Motors Pty Ltd.
Specifications subject to change.
